Electroorganic Synthesis under Flow Conditions
- Mohamed Elsherbini
- Thomas Wirth
- School of Chemistry, Cardiff University, Main Building, Park Place, Cardiff CF10 3AT, United KingdomRead the publication that featured this abstract
Despite the long history of electroorganic synthesis, it did not participate in the mainstream of chemical research for a long time. This is probably due to the lack of equipment and standardized protocols. However, nowadays organic electrochemistry is witnessing a renaissance, and a wide range of interesting electrochemical transformations and methodologies have been developed, not only for academic purposes but also for large scale industrial production. Depending on the source of electricity, electrochemical methods can be inherently green and environmentally benign and can be easily controlled to achieve high levels of selectivity. In addition, the generation and consumption of reactive or unstable intermediates and hazardous reagents can be achieved in a safe way. Limitations of traditional batch-type electrochemical methods such as the restricted electrode surface, the necessity of supporting electrolytes, and the difficulties in scaling up can be alleviated using electrochemical flow cells. Microreactors offer high surface-to-volume ratios and enable precise control over temperature, residence time, flow rate, and pressure. In addition, efficient mixing, enhanced mass and heat transfer, and handling of small volumes lead to simpler scaling-up protocols and minimize safety concerns. Electrolysis under flow conditions reduces the possibility of overoxidation as the reaction mixture is flown continuously out of the reactor in contrast to traditional batch-type electrolysis cells.
In this Account, we highlight our contributions in the area of electroorganic synthesis under flow conditions over the past decade. We have designed and manufactured different generations of electrochemical flow cells. The first-generation reactor was effectively used in developing a simple one-step synthesis of diaryliodonium salts and used in proof-of-concept reactions such as the trifluoromethylation of electron-deficient alkenes via Kolbe electrolysis of trifluoroacetic acid in addition to the selective deprotection of the isonicotinyloxycarbonyl (iNoc) group from carbonates and thiocarbonates. The improved second-generation flow cell enabled the development of efficient synthesis of isoindolinones, benzothiazoles, and thiazolopyridines, achieving gram-scale for some of the products easily without changing the reactor design or reoptimizing the reaction parameters. In addition, the same reactor was used in the development of an efficient continuous flow electrochemical synthesis of hypervalent iodine reagents. The generated unstable hypervalent iodine reagents were easily used without isolation in various oxidative transformations in a coupled flow/flow manner and could be easily transformed into bench-stable reagents via quantitative ligand exchange with the appropriate acids. Our second-generation reactor was further improved and commercialized by Vapourtec Ltd. We have demonstrated the power of online analysis in accelerating optimizations and methodology development. Online mass spectrometry enabled fast screening of the charge needed for the cyclization of amides to isoindolinones. The power of online 2D-HPLC combined with a Design of Experiments approach empowered the rapid optimization of stereoselective electrochemical alkoxylations of amino acid derivatives.
